Aluminum formwork system

The aluminum formwork system is a construction system for forming a cast-in-place concrete structure of a building. It is also a system for scheduling and controlling work in other construction industries, such as steel, concrete pouring and mechanical and electrical piping.

The system is fast, simple, adaptable and cost effective. It is unique in that it forms all the concrete in the building, including walls, slabs, columns, beams, stairs, curtains, balconies and various decorative features, which are fully in line with the architect's design. The dimensional accuracy of concrete works also leads to the consistency of the door and window fittings. The smooth surface treatment of concrete eliminates the need for expensive plastering.

Unlike other building systems, the aluminum formwork system can be built by unskilled labor and does not require a crane. The largest panel weighs no more than 25 kg, which means it can be handled by one worker.

During construction, the cost of aluminum formwork and scaffolding accounts for 20%-30% of the total cost, and the removal of aluminum formwork and scaffolding accounts for 5-50% of the total time. Therefore, an excellent templating system can achieve high efficiency, low carbon, energy saving and environmental protection goals. Aluminum stencils have significant advantages over traditional wood stencils.

Advantages of the aluminum formwork system:

Short construction period and high efficiency: The aluminum formwork system is a rapid prototyping and disassembly system that usually takes 18-36 hours to remove. Therefore, it is possible to use only one layer of aluminum template plus three single supports, and usually one layer is constructed for 3-4 days. Therefore, the construction period is greatly shortened, the construction unit saves administrative expenses, and the real estate developer shortens the development cycle.

The cost of reusable is low: the configuration of the adjustment template can be reversed more than 300 times, and the use cost is low.

The structure is simple and the efficiency is high: the aluminum template system is simple to assemble and convenient to install, and only needs to increase the standard plate proportionally, and the light aluminum template per square meter is 18-25KG. The construction process is completely assembled and transported by hand; it does not depend on lifting equipment.

Good stability, high capacity: capacity up to 60KN

Wide range of applications: The aluminum formwork system is suitable for all building components, such as load-bearing walls, columns, beams, stairs, balconies, etc., which can be used immediately by cement casting.

Feature

High strength, light weight, easy and fast operation.

Convenient transportation, teardown.

Efficient construction.

Clean the construction site, the surface is smooth and improve the quality of the project.

Standard, universal, high re-use rate, low average cost.

High carrying capacity and good stability.

Environmental protection, high recycling value.

Application

The aluminum formwork assembly is used to connect the formwork for support and fastening. Concrete structure. Exhibition settings. High-rise building. Social housing tower. Internal renovation.
